And along with two dedicated expression pedal jacks, there's an additional control jack with a three-way mode selector. Footswitch for BOSS and Roland amps, 6 Switches, 2x Expression Pedal Input for Drive and Volume Control, Compatible with BOSS Katana. Status LEDs with two colours make it easier to see changes when switching. The GA-FC EX builds on the standard GA-FC with several enhanced features. It maintains the simple setup and intuitive workflow of the standard GA-FC while offering additional functions for greater performance flexibility. If revised in future I will change this to another pin.The GA-FC EX provides expanded foot control functionality for select BOSS amplifier models. Boss Katana 110B Bass Amp Combo (60 Watt Class AB) BOS-KTN110B. This is because I used pin 13 which is the pin for the built in LED. Use the Roland GA-FC GA foot controller to drive your Boss or Roland amp from the ground.

  • LED for Channel B-2 will remain on dimly at all times.
  • See the Layout-1032L branch for the changes I used. Using a 4 in line enclosure you will either need to adjust the output pin order, or you will have to use some non-optimal wiring. My build used a 1032L, though a Hammond 1590BX is similar in size, though shallower, and will probably work well too if care is taken to fit the PCB. The PCB was laid out with a 1590BB in mind. I used JLCPCB in China to manufacture the boards. The files to make a board can be found in the /GerberFiles folder. This is something I may address in a future iteration. This is 76x36mm in size, so is a bit awkward to fit in some enclosures with the switches and LEDs. Use an LED Calculator, the supply voltage will be 5V, the forward voltage and current will depend on your LED, check the datasheet.Ī PCB design is available for convenience as used in my own pedal.
  • R1 220Ω - Current limited Resistor (CLR) Channel 1*įor resistors R1-R4 you may need to change the value dependent on your chosen LEDs.
  • Going beyond standard distortion, delay, and reverb, the selection includes. Connecting to BOSS Tone Studio via USB provides access to 65 fully customizable effects, and you can load your favorites into the amp’s various effects sections. Note: On the Arduino Nano used pins A6 and A7 are analogue input only and will not function in digital mode as either an input or output. With its built-in BOSS effects, the Katana-50 lets you perform anywhere with just a guitar and amp. These are all defined in constants at the top of the file.

    #BOSS KATANA FOOT CONTROLLER UPDATE#

    If you create your own then you may need to update the pins used for the switches in and the LED outs. Its a vital companion to thousands of players worldwide seeking to. Its clear and easy to operate, with six separate switches, so theres no. The GA-FC is the master foot controller for most stage-ready BOSS and Roland amps. If you connect a TRS cable to the amp end only then it will switch to B-2 as the amp detects the jack but the connections are open. The GA-FC is the master foot controller for most stage-ready BOSS and Roland amps. The map of channels to connections is below, with HIGH meaning the connection is shorted to the sleeve and LOW meaning open circuit. The channels and banks are selected by shorting either the tip or ring to the Sleeve. Basically you can make them, but don't sell them. This project is considered to be Creative Commons Attribution-NonCommercial-ShareAlike. Note: This will also work with the Katana 100 line but the GA-FC foot-switch will do the same off the shelf. To enable foot-switching simply insert a TRS cable into the foot switch jack.

    #BOSS KATANA FOOT CONTROLLER MANUAL#

    The Katana 50 foot-switch jack is a TRS (Stereo) connection with Tip switching the channel and Ring switching the bank. FOOT CONTROL jack (1/4-inch TRS phone type) Accessory Owner's Manual Foot Controller Cable Options (sold separately) Expression Pedal (Roland EV-5, BOSS FV-500L, BOSS FV-500H) Size and Weight Width 392 mm 15-7/16 inches Depth 81 mm 3-3/16 inches Height 49 mm 1-15/16 inches Weight 1.0 kg 2 lbs. This pedal features 4 momentary switches giving access to all 4 channels via a single button press. Say you wanted to change from A-1 to B-2 this would require both buttons to be toggled, one to swap channels and the other to swap banks. Normally a 2 button latching foot-switch is used, one switching channels and the other switching banks. FOOT CONTROL jack (1/4-inch TRS phone type) Accessory Owners Manual Foot Controller Cable Options (sold separately) Expression Pedal (Roland EV-5, BOSS FV-500L, BOSS FV-500H) Size and Weight Width 392 mm 15-7/16 inches Depth 81 mm 3-3/16 inches Height 49 mm 1-15/16 inches Weight 1.0 kg 2 lbs. BOSS TONE STUDIO for RC-202 is available.

    #BOSS KATANA FOOT CONTROLLER CODE#

    KatanaSwitch is the Arduino firmware code for a basic 4 button foot switch for the BOSS Katana 50 amplifer. The famous BOSS Slicer effect returns in an advanced compact pedal.
